High Performance Gsurface V P3.9 P4.81 P6.25 P7.81 P10.4 Outdoor Digital Advertising Board For Commercial Use

Brand Name : GCL

Model Number : Gsurface V

Certification : EMC/CE/ROHS/CCC/FCC/BIS

Place of Origin : Guangdong, China

MOQ : Min. order: 20

Price : Price to be discussed

Delivery Time : 7-20 days

Application : Outdoor

Type : LED

Color : Full color

Panel Size : 1000*1000 mm

Supplier Type : Original manufacturer, ODM, OEM

Media Available : datasheet, Photo, EDA/CAD Models, Other, video

use : advertising publish, retail store, shopping mall, display of dishes, welcome display, self-service business, exhibition hall, wayfinding, airport, subway, elevator, Restaurant & Hotel Supplies, education, medical treatment

Pixel Pitch : 3.91mm, 4.81mm,6.25mm,7.81mm,10mm,

Specification : Digital Poster, Video Wall

Touch Screen Type : Capacitive

Brightness : 6000-10000nits

pixel density : 10000

Contrast Ratio : 9000:1

Color Depth : 256

Lifespan (hours) : 100000

IP Rating : IP65

HS Code : 8528591090

Resolution : 3840Hz

View Angle（H/V） : H120°,V120°

Module size : 480*320mm

Cabinet Material : Alumium

LED Type : SMD1921 ,SMD2727

After-sales Service Provided : 3 Years

Scan Method : 1/2

Cabinet Weight : 29.48KG

Maintenance : Front & Rear Service

Grey Scale : 13-16 bit

Contact Now

High Performance Gsurface V P3.9 P4.81 P6.25 P7.81 P10.4 Outdoor Digital Advertising Board For Commercial Use

Fully enclosed module with excellent waterproofing:
It matches professional waterproof enclosures, waterproof modules, and waterproof power boxes, with an IP65 protection rating, suitable for installation in various outdoor weather conditions.

Low power consumption, high performance:
Minimum power consumption of 200W, stable operation 24 hours a day, with a module lifespan of up to 100,000 hours.

Multiple box options are available:
The aluminium profile box is lightweight, weighing 29kg. The standard box measures 1000×1000mm, with custom sizes available for 1000×750mm and 1000×500mm boxes.

Different boxes can be installed in a mixed arrangement:
Products can be flexibly matched according to project size requirements, suitable for various installation spaces, saving on inventory costs.

Supports front and rear maintenance for quick installation:
Convenient maintenance and installation without complete disassembly; modules can be removed in just 2 seconds and can be installed or taken out from both the front and rear, making bi-directional maintenance easier.

Corner and Right Angle Assembly:
Designed with a 45-degree sloping base, it can be assembled at angles; the P6.67 to P10 models can be paired with seamless corner designs to create a naked-eye 3D large screen.

Parameters of GsurfaceV Series:

Product	P3.91	P4.81	P6.25	P7.81	P10.4
Pitch	3.91mm	4.81mm	6.25mm	7.81mm	10.4mm
Density(pixels/m²)	65536	43264	25600	16384	9216
LED Type	SMD1921	SMD1921	SMD2727	SMD2727	SMD2727
Brightness	5500nits	5500nits	6500nits	6500nits	6500nits
Scan Method	1/8	1/13	1/6	1/4	1/2
Panel Size	1000×1000×78mm
Module Size	500×250mm
Panel Material	Profile Aluminum
Panel Weight	29kg
Protection Level	IP65
Maintenance	Front&Rear Service
Max Power Consumption	600W/㎡	600W/㎡	650W/㎡	650W/㎡	650W/㎡
Average Power Consumption	200W/㎡	200W/㎡	210W/㎡	210W/㎡	210W/㎡
Refresh Rate	3840Hz
Grey Scale	13-16bit
Viewing Angle	H140°,V120°	H140°,V120°	H140°,V120°	H140°,V120°	H140°,V120°
Voltage	AC100~240V(50-60Hz)
Working Temperature	’-30℃ to 60℃
Working Humidity	10%-90%RH
Color Temperature	3000-9500K
Certifications	CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO
