Fixed installation Advertising LED Display Screen

Place of Origin : Guangdong, China

Model Number : Gpro

Brand Name : GCL

Packaging Details : wooden case,plywood,flight case,paper board

Supply Ability : 2000 Square Meter/Square Meters per Month

Price : 1 - 49 pieces $445， 50 - 99 pieces $440， >= 100 pieces $435

MOQ : Min. order: 20

Certification : EMC/CE/ROHS/CCC/FCC/BIS

Application : Outdoor, Advertising/Fixed installation, Video Advertising

Type : LED

Color : Full Color

Panel Size : 640x960mm, 640x960mm

Supplier Type : Original manufacturer, OEM

Media Available : datasheet, Photo, EDA/CAD Models, video

use : advertising publish, shopping mall, welcome display, exhibition hall, Large Commercial Complex, Large Sports Center, Urban Landmark

Function : SDK

Pixel Pitch : 10mm, 10mm

Specification : Video Wall

Touch Screen Type : Capacitive

Brightness : 6000-10000, 6000-10000, 10000cd/m2

pixel density : 160000, 160000

Contrast Ratio : ≥9000:1, ≥9000:1

Lifespan (hours) : 100000, 100000

IP Rating : IP65, IP65

Resolution : 400-16384

View Angle（H/V） : H140°,V140°, H140°,V140°

Display Type : outdoor

Product name : Gpro

Viewing angle : H140 V140

Warranty : 3 Years

LED type : SMD 1415

Port : shenzhen

Contact Now

GCL Gpro Outdoor P6 P8 P10 Ultra HD Big LED Advertising Videowall Screen for Large Shopping Malls P2.5P4P6P8P10P16

Products Description

High Brightness

High-quality LEDs can reach 10,000 nits. The pixel pitch are P2.5,P4, P5.7, P6.6, P8, P10(DIP ),P16(DIP);

High Resolution

Fine pixel pitches form high resolution, which can capture and hold the attention of passerby.

Visual Performance

High contrast: The contrast ratio of the LED screen gives a sharp image quality.

High brightness: The brightness of the LED Display can be up to 10,000 nits. Even the screen is facing directly sunlight, the image still looks clear.

Energy Saving

We use customized PCB and power supply, so average power consumption is less than 130W/sqm.

Fixed installation Advertising LED Display Screen

1.Double Water Proof,Module Water Proof,Cabinet water proof,which can be able to withstand extreme weather

2,Front and Back service This Panel is for outdoor use,and has achieve Front and Rear maintenance,Super thin and light weight,only 85mm thickness,and 16.5kg

3.Good Heat Dissipation,No need AC and Fan,No noise 3.Excellent Quality Our field-tested LED panel is a self-contained, modular unit made of die-casting aluminum to provide superior heat dissipation,durability, and a longer lifespan. Unlike most digital signs, ours have no fans. This unique product meets strict quality controland is backed by a 3 year warranty.

4,Multiple installation mode,can be hanging or wall mounted.

5,Energy Saving,Compared with normal led screen,SMD led panel save 30%,DIP led panel save 50%,only 300w/sqm

Product Parameter

Product	P2.5	P4	P5.9	P8	P10	P10D	P16
Pitch	2.5mm	4mm	5.92mm	8mm	10mm	10mm	16mm
Density(pixels/m²)	160000	62500	28476	15625	10000	10000	3906
LED Type	SMD1415	SMD1921	SMD2727	SMD2727	SMD2727	DIP346	DIP346
Brightness	6000nits	6000nits	7000nits	7000nits	7000nits	8000nits	8000nits
Scan Method	1/16	1/10	1/6	1/4	1/2	1/4	Static
Panel Size	640×960mm
Module Size	320×320mm
Panel Material	Die-casting Aluminum
Panel Weight	23.5Kg	23.5Kg	19Kg	19Kg	19Kg	21Kg	21Kg
Protection Level	IP65
Maintenance	Front/Rear Service
Max Power Consumption	650W/㎡	720W/㎡	720W/㎡	720W/㎡	720W/㎡	350W/㎡	350W/㎡
Average Power Consumption	210W/㎡	240W/㎡	240W/㎡	240W/㎡	240W/㎡	110W/㎡	110W/㎡
Refresh Rate	3840Hz
Grey Scale	13-16bit
Viewing Angle	H160°,V140°					H100°,V50°
Voltage	AC100~240V(50-60Hz)
Working Temperature	-30℃ to 60℃
Working Humidity	10%-90%RH
Color Temperature	3000-9500K
Certifications	CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO

Our Advantages

1.GCL has been a professional led display suppier for 23 years.

2.Provide 3 years or more warranty but 95% supplier provide only 2 years.

3. Free technique training and can send engineer to your country to help with the led project if requested.

4.GCL based in shenzhen and we have warehouse and office in Dallas, The united states,and Russia

Product packaging

To protect the LED screen well during the long transportation :
1) If it's for rental use, we will pack all cabinets by flight cases;
2) If it's for fixed installation, we will pack all cabinets by plywood cases .

FAQ

Q1. Is GCL a manufacturer or a trading company? Manufacturer. GCL has been a professional LED screen manufacturer for more than 21 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.

Q2. Why is the Alibaba account of your company only one year old? We have two Alibaba accounts, both under the same company name. The first one is 11 years old. To boost our sales, we registered a new Alibaba account in 2020.

Q3. I have never cooperated with your company before, nor have I visited your factory, how do I know that your company is trustworthy? GCL was founded in 1999, we are the most experienced LED display factory in China. All of our company information displayed on Alibaba, including our company video, has been verified by Alibaba. The fact that we have done a lot of magnificent government projects all over the world proves that we are a very professional company. The fact that we provide 3 years warranty while all the other companies provide only 2 years proves that we are more confident about our product quality. You can do the purchase and transfer the money through Trade Assurance on Alibaba, which would 100% project you from any fraud.

Q4. How long is the warranty? The standard warranty is 3 years. It could be longer upon request. During the warranty, we would send the engineer team to the customer’s country for the maintenance of our products for free twice per year.

Q5.What is your payment terms? Standard payment terms:30% T/T deposit, 70% T/T before shipment. Other payments terms could also be acceptable upon negotiation;
